So you got yourself one of those hanging air filtration thingies for your shop yay you! That was a smart move. Now how in the world are you going to get that heavy beast up to the ceiling?

Even with assistance, they can be a real bear to hang without injury. The larger, the more difficult. I was given this air filtration unit back when I inhabited a different shop. There has to be mounting jet air filtration 3.0 better way.

Finally ready to hang it in my current shop, again Mounting jet air filtration 3.0 was able to do the job by myself and without injury. You still have mounting jet air filtration 3.0 lift half of the weight over and over while working on a ladder. Use a tall enough ladder that you always have something to lean on while lifting.

But since I have no ceiling, it was easy to add a spanning joist to which I could fasten the hardware. In my previous shop which did have a ceilingI bolted a pair of 2x4s mounting jet air filtration 3.0 the ceiling — each spanning and attached to 3 joists — to provide my anchor points.

Whatever your setup, be sure the weight of the air filter is ultimately supported by solid joists and not by toggle bolts through drywall. Once you have your spacing figured out, drill the appropriate size pilot holes for the eye lags and screw them into the joists. The shank and threads measure only an inch long. I made the rookie mistake of naively assuming my main joists were precisely aligned.

As a result, I got the eyes about an inch closer together on one end. Especially with framing construction. Connect an S-hook and chain to each eye screw. None of that wimpy, unwelded swag lamp chain. Some shop air filters come with hooks on top, but most have eye bolts. The rest of us can either replace the eyes with hooks or use S-hooks as shown. You will have only one free hand to work with. So after connecting the S-hooks to the air filter, wrap some mounting jet air filtration 3.0 to keep them upright and at attention.

Doing so makes it much easier to connect the chain with one hand while lifting the unit with the other. By now, you can probably see where this is going. As you work your way higher and higher, always keep an eye on the chains opposite you. If one slips off, reattach it before proceeding. The other ladder was no longer cutting it at this point. I needed something to lean on while lifting the weight near ceiling level, so I switched to a taller ladder.

Finally, once you reach the desired height, cut off the excess chain. Or you can just double up the S-hooks by hooking the ones from above through the eyes on the air filtration unit.

And hooking the ones on the filter unit through the eyes on the ceiling. At many times during the process, the weight will temporarily be supported by only three corners. Once you have the unit positioned where you want it, however, check that the load is distributed among all four.

If one has slack, adjust an eye screw or hook to snug it mounting jet air filtration 3.0. And there you go — one shop air filtration system suspended from the ceiling. If and when you mounting jet air filtration 3.0 need to take it down again, simply reverse the process. Your friends might wonder how you managed to do it all by yourself. Steve made his first woodworking project at age 9 in and whittled his first wooden chain at He was also a consumer electronics repair tech and shop owner for a little over 20 years, until his impending obsolescence became impossible to ignore.
