lathe-tools-inserts-query Indexable Cutoff and Grooving Carbide Inserts. Be sure to make sure everything is wuery and secure, and follow all your good lathe practices before taking cuts. These tools feature a steel lathe tools inserts query, with a carbide tip brazed onto the end. Relief Angle. HSS Tooling can be very versatile and economical, especially if you don't plan on using the lathe very much, or you don't know what kind of parts you will be making.

T-shape: three edge, long edge and low strength. The insert with offset angle is often used to improve the strength of tool tip. The inner hole turning tool is mainly used for processing blind hole and step hole.

C shape: there are two kinds of insert angle. It can be used to process the end face or cylindrical surface without changing the tool. The inner hole turning tool is generally used for processing step holes.

R-shape: round cutting edge, used for machining special circular arc surface, with high insert utilization rate but large radial force. It is mainly used for profiling. Generally, the cutting insert which directly presses the chip breaking groove is used on the numerical control lathe. It can make the chip transverse contraction deformation, cutting is light and fast, and chip breaking is reliable. In addition, its side deflection angle and side back angle are very large, cutting heat generation is less, service life is long, but the price is higher.

For example, vertical grooving insert, flat grooving insert, strip grooving insert and step clearing arc root groove insert, the groove width accuracy of these inserts is high.

L-shaped insert is commonly used. For the thread with high cutting accuracy, the insert with good tooth shape should be used. Because of the different tooth shape sizes of the internal and external threads, it is divided into internal and external thread inserts. Its pitch is fixed and can be used to cut out the top of the tooth. As a clamping method, there are two kinds of clamping methods: one is the insert without hole, which is clamped by upward pressure type, and the other is the insert with chip breaking groove and clamping hole, which is clamped by pressing hole type plum blossom screw.

Cutting edge length: it should be selected according to the back feed. Generally, the cutting edge length of slotted insert should be no less than 1. Tool tip arc: when rough turning, as long as the rigidity is allowed, it can be touched as much as possible.

Generally, the radius of tool tip arc is smaller when the rigidity is allowed. However, when the rigidity is allowed, it should be selected from a larger value.

The commonly used circle radii for pressing are 0. For example, some ceramic inserts need to use thicker inserts. The rough and semi finishing machining of ordinary lathes is of class u, and those with higher requirements for the position of tool tip or CNC lathes use M, and the more advanced ones use G.

Choices range from small threading tools, to massive 2" boring bars. Choosing the best ones for you can be difficult. If you do not have in a mind a certain type of part you'll be making, a general purpose group of tools, that can turn, face, and bore will probably be your best bet. The KBC Tools catalog has a great section on indexable carbide tools, with diagrams as to what type of cutting each tool and insert can do.

Both of these tools use CCMT If you are unsure about what to get, those two tools will cover most all of your turning, facing, and boring needs, at a great price. Once you have tools, you will need inserts. Most tool stores that sell indexable carbide tools, will also sell the inserts. If you have trouble finding the inserts, you may want to look into a different tool, one with more common inserts, as this will save you time and money later.

Again, the KBC Catalog has a great section describing almost all common inserts, and breakdown of the naming conventions. I bought my inserts from maritool. Large nose radiuses. I chose a selection of inserts, positive rake, Kennametal K68 inserts for aluminum, and neutral rake CeraTip CA inserts for steel and stainless. Positive rake inserts will reduce horsepower requirements in soft metals, but can break off in hard materials. Neutral or negative rakes are much stronger in hard materials, but require more horsepower to push through the cut.

Toolholders are what attach your tools to the lathe. Most modern lathes , and all the techshop lathes, are equipped with quick change tool posts Shown above. These are special tool posts, that allow you to quickly swap tools, while maintaining the same height for each tool.

The majority of the rest of this instrucable will cover set-up with quick change posts. If you have another type of toolpost, the same Lathe Tools Inserts Kit general rules apply, but the methods for setting tool height will be different. If you just got your lathe, the toolpost should say which series it is. All series toolholders will fit the series toolpost, and similarly, for series holders and posts.

However, a series toolholder would not fit on a series toolpost. The toolholders themselves are also standardized. Different varieties typically come in all common toolpost sizes. For most turning and facing tools, a 1 or 2 toolholder will be the best choice. For boring bars, a 2 or 4 holder will be best. You have to choose smaller tools based on your toolpost. Here, I chose a single BXA 2 toolholder. Once you have your tooling and holders, you need to prepare everything to go in the lathe.

If you tooling didn't come with inserts installed, that will be your first step. Changing the inserts is very simple, simply unscrew the clamping screw, and remove the insert. You will want to be careful of chips and debris when changing inserts, as they can cause inconsistencies between inserts. For setting the tool height, it also recommended that you use an insert you don't care too deeply about, as it is possible to break.

Next, install a tool into your toolholder. Again, be sure to clean both the tool, and the toolholder, as even small chips will cause inconsistencies. Place the tool in the slot, and tighten the set screws as shown. You will want to get these set screws decently tight, if they are loose they can vibrate free. Now that your tool has inserts installed, and is in a toolholder, you are ready to install it on the lathe.

It is again recommended to clean all the surfaces on the toolholder, and toolpost. To install your toolholder, rotate the large handle on top Lathe Tools Inserts Journal of the toolpost counterclockwise, until the small gibs raises up.

Then slide you toolholder onto the approiate dovetail slot. Push the tool all the way down, and rotate the handle clockwise until tight. In this operation, you will be setting the tool height relative to the machine. The ideal height for each tool varies, because the cutting edges sit at different heights on each tool.

However, all tools will cut best when the cutting edge is directly on the centerline of the spindle. For quick change toolholders, the height is set by adjusting the thumbscrew and locking nut. On traditional 4 way toolposts, shims must be added under the tool.

To set the height you will want something long, and relatively flat, with two parallel edges. A steel rule, works great for this. You will also want a piece of round of decent diameter. This method will in theory work with any diameter, but it will be more difficult as the diameter goes down.

I used a piece of 2" aluminum round I had leftover. With the machine off, chuck the round stock in the chuck, and tighten. You will be cutting with it, so don't skimp on the chucking. Next, move the tool until the cutting edge is in a position to contact the outer diameter of the work piece. Take your rule, or other object, and hold it so it so the cutting edge of the tool is roughly centered on the length of the rule. Then, advance the X axis until the cutting edge just contacts the rule.

Be careful, to much pressure will break the carbide. You should now be able to let go of the rule, and it should stay in place. If not, keep putting light pressure on the Lathe Tools Inserts Usa axis until it stays. Now, postion yourself so you can get a good look directly at the front of the spindle. If the tool was perfectly level, you would see the rule perfectly vertical, however, unless you are extremely lucky, it is most likely angled.

If the rule is angled such that top is closer to the spindle center, the tool is too high. Similarily, if the rule is angled such that the bottom is the closer to the Lathe Tools Inserts 2020 spindle center, the tool is too low.

Take note of the angle of the rule, and decide which way to move the tool. Then, remove the tool from the toolpost. Loosen the locking nut on top the thumbscrew, and rotate the thumbscrew so it moves either up or down.

There is no direct science on how much to move the thumbscrew at this point, so you should use your best judgement, if it is wrong, there will be no harm. Once you have moved the thumbscrew, tighten the locking nut, and re-install the tool. Repeat the rule test, and thumbscrew adjustment until the rule is too your best judgement, vertical. It does not have to be dead nuts perfect at this point, as you will continue to dial it in.
