As with many other woodworking tasks, routing hinge mortises requires precision and consistency for flawless results. So build this made-to-size jig specific to the hinges you're using, and you'll get repeatable, accurate results with little effort.
This jig works with a pattern bit which has the bearing mounted above the cutters. As the bearing rides against the himge of the jig opening, the cutters rout the mortise to the same size as the opening.
Longer bits require thicker jig material to work smalll the same way. Capture the hinge leaf with the jig's center strips and side pieces, apply glue to their edges, and clamp them together to s,all the jig's face.
Begin by measuring the short edge of a hinge leaf, excluding the barrel. Double that measurement to determine the width of the jig's center strips mortiae, below ].
Crosscut both in half. With those four pieces cut, assemble the jig's face, photo below. Next, clamp the jig's face to the door, photo below. Use a pencil to mark the jig along the door's ends; then, cut along those lines to bring the jig to final length. Mark the center of the hinge's barrel on the jig face, photo below.
Glue and screw this hinnge perpendicular to the underside of the jig, edge abutting the marked line, covering the hinge-barrel-side of the bit opening. Line up the bit opening with the hinge location on the edge of the door. Mark the jig along the door's end.
Repeat for the other end of the door and jig. Hold the closed hinge inside the bit opening, leaf-side tight to an edge. Mark the jig at the center of the hinge barrel -- the location of small box hinge mortise jig support arm.
First, use a small box hinge mortise jig to set small box hinge mortise jig router bit's cutting depth, photo below. Then, align the support small box hinge mortise jig bottom edge with the bottom edge of the door, clamp it in place, and rout the mortise as shown above.
Repeat at the top edge of the door. To rout mating mortises in the cabinet, clamp the jig's support arm to the face frame's stile, see photo below. Finally, with the mortises roughed out, square up their corners with a chisel. Then, install your hinges. Place the jig face-down on your router's subbase. Set cutting depth equal to the thickness of small box hinge mortise jig hinge's mortisse plus the jig face.
Before you mount the jig to the cabinet, slide a penny between the jig and the face frame to give the door a proper reveal. Quick Tip! Use brass screws that come with the hinge only after drilling pilot holes and applying wax to the screws to prevent them from binding and breaking.
