Sargent and After: Including Hercules. The lateral adjuster on a Ohio Tools made plane. Note this twist is slightly different than Drawer For Under Bench Name the Sargent or Union. That lateral adjuster of a Union looks like the early twisted Sargent, but with a washer type guide like the Ohio Tools or Stanley. See more on this Here.
Email Address. Vintage Stanley made: Stanley type study The lateral adjuster on a Stanley made plane. Sargent and before: The Sargent twisted lateral had 2 different guides, The type 2 horseshoe style on the left and type 3 bent type on the right Sargent and After: Including Hercules Millers Falls made : That lateral adjuster on a Millers Falls made plane.
Mouth — The terms mouth and throat are frequently used interchangeably. Technically, the mouth is the opening in the sole of the plane through which the iron protrudes. The throat is the area just above the mouth on the top side of the body through which the shavings pass. The sole is milled flat on most bench and block planes, although there are specialty planes with adjustable soles, such as the flexible Stanley no.
Threaded Adjuster Rod — This threaded rod is attached to the back side of the frog and is the mounting post for the depth adjusting nut. The nut threads onto the rod and engages the yoke just above it. Tightening the nut moves it forward, which in turn causes the yoke to pivot upward, thus raising the iron.
Loosening the nut does just the opposite, lowering the iron. Throat — The terms mouth and throat are frequently used interchangeably. Tote — The rear handle on a plane is called the tote.
Like the knob, totes were typically made of rosewood, hardwood, or some other species, depending on the manufacturer. Stanley also offered aluminum totes for a period back in the s and 30s as a more durable option for trade schools and such. Totes on smaller planes are secured via a tote bolt alone, while totes on the larger planes have a screw added at the toe for additional support.
Tote Bolt — Identical to the knob bolt, only longer, the tote bolt secured the tote through a hole drilled through its length, capped off by a tote nut. Tote Nut — Stanley and most manufacturers used a brass nut to secure their knobs and totes via their respective bolts. The screw was blued at least until WWII. It has a round slotted head and screws into the base of the plane through the toe of the tote.
Yoke — The yoke is a small wishbone shaped device that is attached to the top of the frog just above the threaded adjuster rod. Made of cast iron, it is brittle and will easily break.
The fork of the yoke engages a wide shoulder notch in the depth adjustment nut. As the nut is turned, the opposite end of the yoke that protrudes through the face of the frog engages the rectangular hole in the cap iron, raising and lowering it. Like Like. You are commenting using your WordPress.
