Full set of 24" x 36" 40 to 50 page CNC router plans sets with assembly instructions. We decided to bring back the successful CNC router plans option, but to instead offer the plans for the newest and most advanced CNC models. The plans can even include the laser cutter and engraver machine gantry and 4th axis attachments. The CNC router plans come in a 24"x36" 40 to 50 page document set.
The sub assemblies with head the part layout and cut sheets. All of the part are laid out at one-to-one scale, so you can lay the sheets right on top of the material and cut it out.
All of the drill holes have a center mark so you can use a punch to provide a divot for better drilling accuracy. Features such as counterbores and pockets are shown either in section or hidden line elevations with dimensions showing the depth at which to cut or drill the feature. If you wish to cut the parts out the traditional way, the parts are fully dimensioned. The plans also include very detailed instructions on properly assembling the machine and sub assemblies.
The instructions will guide you through attaching the parts of the sub assembly of the CNC router and then attaching the sub assembly to the main assembly of the CNC router. The sub assemblies will contain a section that consists of the bill of materials for the specific instruction or step and specifications like wire length, or screw type and size.
To make the assembly instruction very clear and easy to follow, the item that is to be fastened or installed is highlighted with a heavier line weight. Some of the steps for the CNC router plans assembly instructions may contain notes or more elaborate detail, generally focusing on proper mechanical functionality for the CNC router and laser gantry, or the fit and function of the overall CNC assembly.
The plans also show in great detail the cable and wire runs, color coded to discern each wire or cable and to what terminal they are connected, including the names of each terminal and the length of wire required for the routing of the wire or cable throughout the CNC machine.
These plans are intended for anyone that has a desire to build their own CNC machine. No special abilities are needed and as always, we are here to guide you through the process. People often use it to produce advertising signboards, lamp boxes, direction boards, shop windows, and display racks, etc.
While choosing to purchase, the users need to understand the machines and choose the right one based on their demands. Otherwise, if the users choose the unsuitable machine, it will affect the processing effect, and also cause economic loss. This article mainly focuses on the brief introduction, working principles, and the comparison of processing features of the two machines.
And the following also gives suggestions on how to choose a suitable machine. As a professional CNC Machine manufacturer, Blue Elephant has a complete production base, including professional processing workshop, welding workshop, assembly workshop Toggle navigation.
And they both need a computer to design cutting graphics and control the cutting process. The users use the software to design the picture file or cutting route and import it into the cutting machine. Later, the machine automatically completes the cutting process.
It uses the high energy of the laser to complete the cutting or engraving of materials. But the tool of the CNC acrylic cutting machine is a real cutting tool. It uses a cutting head with high-speed rotation to cut and engrave acrylic material. Working principles of the laser cutting machine and CNC cutting machine: The laser acrylic cutting machine emits laser and makes it form a high-power density laser beam through the optical system.
The laser beam irradiates on the surface of the acrylic work-piece. And such a work-piece will reach the melting point or boiling point. At the same time, the compressed air coaxial with the beam blows away the molten or vaporized acrylic materials. As the laser beam and the work-piece moves, the cutting graphics appear on the acrylic material eventually. In this way, the laser acrylic cutting machine completes the cutting processing.
CNC acrylic cutting machine relies on the high-speed rotation of the cutting head driven by the motor spindle. It cuts and engraves the acrylic material fixed on the worktable through the tool according to the processing material.
And the machine can also engrave various plane materials or 3D embossing graphics according to the designs on the computer. And it can realize automatic Laser And Router Cnc Machine Controller cutting operation. Processing characteristics: Laser acrylic cutting machine: Laser acrylic Laser And Router Cnc Machine 05 cutting machine belongs to non-contact processing and does not need to fix the work-piece.
It can protect the surface of thin or soft materials from being scratched or deformed. In addition, the laser beam is very thin, so the cutting marks or engraving graphics can be very small.
Therefore, It is suitable for cutting thin acrylic boards generally less than 20 mm , especially for the processing of small details.
