Many cabinet designers, sign makers and furniture builders who use CNC Routers are very interested in intuitive methods for carving and sculpting and for enhancing their work with 3D relief carvings. You may consider having the 3D design and modeling work done by other resources, such as CNC-ready dimensional clipart. Email us. Typically when you get 3D clipart files you need to bring these files through a 3D tool path generating program.

MeshCam The problem with the generic 3D models on the web is that most of them were created for purposes other than 3D machining. They are often too low a resolution for smooth carving and many have errors that make machining difficult. Often times the models are not suited well for scaling to different sizes. A good model has enough detail to be cut in small or very large sizes. We have solved that problem here at makecnc and supply models for your projects right here in our store or if you can't find what you need you can request custom relief models to be made and we will try and produce what you are looking for at a reasonable cost.

Digitizing can do some truly amazing things. A great way to produce 3D shapes without software is to digitize an existing object or part using a digitizing probe or laser scanner. You can use a digitizing probe to produce the 3D shape of a part, or you can probe to get the 2D outline of a part.

The probe is just a switch that is triggered when the tip of the probe contacts the surface of your sample part. When digitizing your 3D part by probing your machine will move the probe tip in a raster pattern.

Through this it will contact and record the position of each contact in order to reconstruct the part shape for cutting. The control software you use has probing functions that allow you to save two types of files. You can save a part file of instructions that is ready to cut at the end of the probing process. Also, if you need to do some modifications to the shape before creating your final file, you can save a file of 3D points.

You can also save a file of polylines that you can use directly as a sole entity within your 3D software. You can also process the 3D points into a 3D surface file using the "probe to surface" virtual tool in your software. You can then do more editing by bringing your creation into your 3D modeling software. Probed parts can actually be scaled in 3D CAM programs to make your object larger or smaller.

Of course, you don't even have to deal with software if you don't feel up to the task. You may have to send it to someone to modify your design. There are even digitizing services you can go to as well if you don't want to go down that route yourself.

It's really all up to you. Of course our discussion wouldn't be complete without mentioning working in 3D in four, five or more axes. These tools machine or carve in 3D by moving the tip of the cutter in these three axes, usually with a back and forth motion rastering in the X and Y axis and a simultaneous up and down action in the Z axis.

The cutter itself remains in a fixed vertical orientation. So the cutting is done in essence by the portion of the cutter that's in contact with the material. This is called 3D relief machining. It doesn't allow for 3D shapes that have ledges or a shape that needs undercutting but it does give you 3D shape. It also doesn't allow for any kind of cutting or machining that can't be done from vertically above and perpendicular to the X-Y plane.

You have to use another method if you are doing 3D work that requires machining from the side or bottom. Some 3D programs will generate coordinated toolpaths for machining an object from two or four sides.

Then you can accomplish the machining effect that requires machining from the side or bottom. You can accomplish this sort of effect with slicing techniques or by rotating the object and machining from different angles. The only problem is that this solution doesn't fix the problem of moving the cutter around to the side or underneath.

This is where you require more movement capability so you need to add more axes of motion or rotation. That way the orientation of the cutter can be changed, which allows more accurate and efficient 3D shaping.

Then your products can have far more shape and contour. Having more axes also allows cutting into a part from the side as well as diagonal drilling. Having a 4th axis rotary indexing head allows machining parts in the round.

This makes the rotation of a part fourth axis control, which mean you can profile objects just like you can with a lathe but you have the added bonus of doing ornamental turning and free-form carving in the round as well. All in all, the fourth axis is a very freeing way for you to accomplish projects of any kind. View Cart 0.
