workbench-vise-hardware-key The clamp shafts travel in Acetal plain bearings for low friction and long wear Acetal is an engineering plastic developed workbench vise hardware key high speed and high load uses in hqrdware wide range of industrial applications. You must be logged in to post a review. This vise is designed to be used by your Great Grandchildren. JavaScript seems to be disabled in your browser. Vise jaws not included.

Please allow up to 4 weeks for delivery. Vise jaws not included. Shipping weight 18 pounds. Keith Bellamy — August 4, The VX20F vise mechanisms are delivered assembled with the clamp shafts installed. I added some strips of thin cork to my vise chop for added grip. The ability to quick-release this vise is key for me. You must be logged in to post a review. Unlike traditional screw operated vises the VX20F face vise utilizes two smooth steel shafts which slide in and out of housings screwed to the bottom of the workbench.

The clamp shafts protrude through the moveable vise jaw and attach to the customers choice of hand wheel or wooden hub and handle. When unclamped the front vise jaw is free to quickly move in and out to adjust to the width of work which needs to be secured.

The rotation of one shaft is transferred to the other shaft by a flat steel bar which slides against the bottom of the bench top. Small racks mounted to the ends of Wood Vises For Workbench Key the bar engage pinions located on both clamp shafts in the housings.

When one handle is turned the rack and pinion transfers the motion to other handle through the transfer bar so it also turns. It is very similar to the rack and pinion steering used in many cars. Clamping is accomplished by an amazingly simple mechanism. A unique helical cam and a precision disk clutch couples the clamping action in the two housings and allows the smooth shafts to clamp when turned, in effect creating a screw — less screw.

The clamp shafts are pushed rearward, with great mechanical advantage, by the clutch action against the helical ramp of the cam.

To clamp your work you simply slide the front vise jaw against the work piece and rotate the clamp handle to apply as much pressure as you would like, just like a screw. There are no levers or releases and either handle may be used to clamp or unclamp. The VX20F face vise utilizes a very high mechanical advantage clamping action similar to a 7 tooth per inch TPI screw. Traditional vises do not use a TPI greater than 4 because it would take too long to crank in and out. The higher TPI reduces the hand appled force to clamp the work and allows the vise to work exceptionally well with metal hand wheels.

The housings are made from aircraft grade aluminum for strength and then precision CNC machined and anodized. The clamp shafts are made from one inch cold drawn steel, machined, carbonitrided, straightened and then polished. The clamp shafts travel in Acetal plain bearings for low friction Workbench Vise Hardware System and long wear Acetal is an engineering plastic developed for high speed and high load uses in a wide range of industrial applications.

All the other mechanism parts are made of high strength steel. The motion between the two housings is transferred by a unique steel bar that can be infinitely adjusted to provide precise movement. This vise Workbench Vise Hardware Foundation is designed to be used by your Great Grandchildren. JavaScript seems to be disabled in your browser. For the best experience on our site, be sure to turn on Javascript in your browser. When you're working with hand tools, holding the workpiece securely is a must — and a solid bench vise is like an extra set of very strong hands.

It can hold stock in a variety of positions, enabling you to make smoother saw cuts and more steady plane strokes. We carry several types and sizes of vises, including models that permanently attach to your bench and others that can be clamped on and then removed between uses. Here's a little information to help you pick the vise that makes the most sense for your shop. There are two basic types of bench vise: the front vise and the end vise. The front vise, most often installed at the left corner of the long edge of the workbench, is great for holding a drawer side upright while you cut the tails of a dovetail joint or holding a board edge-up horizontally for hand planing.
