vidmar-cabinet-replacement-locks-zip Relocate brackets to desire location and reverse the vidmar cabinet replacement locks zip steps to install carriage and drawer. Choose any size or drawer combination you require Workcenter options. Tools, gloves, cloths, rags, boxes, and other items Optional doors. How do I change the configuration of drawers in a cabinet? Return policy. How do I build a workstation?

Suggestions are welcome. On mine, I took out the first couple of drawers and then reached up behind the top lip of the cabinet and removed a nut on the back of the lock assembly.

Then it came right out. Also, you can pull a couple of drawers and reach into the back of the cabinet and shove the lock bar into a more desirable position. First, thanks for the reply. On mine there is no visible nut. The top of the box is folded down for about 1.

It is further folded back towards the back of the box for about another inch. This forms a three sided beam at the top of the box. Inside this fold is the cylinder.

There is a U shaped bracket welded to the back of box front that houses the cylinder. I can see in and there is no nut bearing against the front of the cabinet. The part of the cylinder that protrudes through the bracket is a cylindrical shape with two splits, degrees apart. The openings in the splits are filled a metal part I cannot see much of - but I did try to depress these parts to see if I could turn the cylindrical part.

No such luck. So I am still stumped. This is a tricky affair, but can be done, practice will make you better. On the cabinet there is a round bore with two male "keys" degrees apart. What you need ideally is a Vidmar key another key which is incorrect will work, you just need something to turn the cylinder body as you depress the keeper from behind.

You will depress the keeper on the same axis as the lock "driveshaft" just towards the front of the cabinet, from the inside. Once the keys and keyways are lined up, the lockset will simply fall out the front with some gentle urging. I strongly suggest you study the situation with a mirror and flashlight with a couple drawers removed. The cylinder can be installed with the keeper past either of the male keys, it is usually a brass color so you can identify where it is.

IOW if you are depressing near the key which doesn't have the keeper it wastes a lot of time. Matt- Thanks for your correct answer. To order additional keys: Please fax the number imprinted on the key along with the shipping and billing information on your company letterhead. EMAIL: custserv3 sbdinc. What kind of locking systems are available for Vidmar cabinets?

We offer a wide variety of locking options to help secure and protect your valuable items. To learn about our locking devices, and for installation help, view our locking instruction manual.

Does Vidmar have cabinets that fulfill lean, 5S, and Kaizen storage requirements? Yes we do! Vidmar 5S cabinets help businesses fulfill lean manufacturing processes by creating improved workflows and organizing workspaces. Click here for more information on our 5S solutions. What are the benefits of Single Drawer Release feature? This patented technology, the first of its kind in industrial storage cabinets, prevents opening more than one drawer at a time. This feature prevents accidental tipping of cabinets from several drawers being opened simultaneously.

This feature must be factory installed. How do I change the configuration of drawers in a cabinet? Changeover process: Remove drawer by opening fully, then lifting the front of the drawer in order to clear the carriage cross member. Remove the carriage by opening fully, then lifting two release latches one per side on carriage to clear carriage brackets. Using a Phillips head screwdriver, remove one screw from each carriage bracket. Remove carriage brackets by lifting upward and pulling forward.

Relocate brackets to desire location and reverse the above steps to install carriage and drawer. How can I customize Vidmar drawers to store specific items? Vidmar cabinet drawers can be outfitted with a number of different accessories perfect for any storage needs. Choose between foam inserts, plastic bins, partitions, trays, custom tool drawers, and more.

How do I change partitions and dividers? Partitions: Remove two hex head screws per partition securing the partition to the drawer bottom. Lift the partition from the drawer slots, move to new location, and reinstall. Fasten with two screws.

Dividers: Remove screws if any to loosen dividers. Lift dividers from partition slots and move to new location. Reinstall dividers; fasten with screws if required. Where are Vidmar products manufactured? Vidmar has been in the Stanley family since while LISTA, a known global leader in modular storage, was acquired in PDF versions of literature can be downloaded from the Literature section of our website.

Where do I find pricing and ordering information? To learn more about specific product and pricing information please view our product catalogs , fill out a request a quote form , browse our Quick Ship Catalog , contact us at orders sbdinc. How can Vidmar assist with weapons storage? The Vidmar vertical weapon storage system is designed to meet the unique needs of military and law enforcement personnel. Our weapon cabinets can be custom configured to securely store any combination of guns, ammunition, accessories, and equipment.

Choose from a wide selection of shelves, dividers, ammo boxes, rifle mounts, barrel cradles, and more. Learn more about our high density weapon storage systems , and weapon cradles. Vidmar will not knowingly quote or sell the STAK System mast and bridge for use with non-Vidmar racking and support structures.

A Yearly Preventative Maintenance Agreement is available. Please contact Customer Service at for detailed information. Are there any Adjustable Rack System restrictions? Applications should fall within the normal ARS product parameters such as Rack Height, Pallet widths and load capacities. Can Adjustable Rack be sold without column and end protectors? What is the maximum height of the Adjustable Rack columns?

Maximum height is: 15' 10". Can the component parts of the hoist ex. The Brake be purchased from Vidmar? No, component parts for the hoist must be purchased through the hoist manufacturer. What are the voltage requirements for a hoist? A standard hoist can be wired to V or V 3 Phase 60 Hertz.

How do I build a workstation? Vidmar workstations are custom configured to suit your individual needs.
