jointer-plane-bevel-up-or-down-pdf Veritas® Bevel-Up Jointer Plane. View Additional Info: Instruction Guide ( KB, PDF). View images (2 total). Product Highlights  Optional 11" long anodized Coopers Jointer Plane Pdf aluminum bevel-up jointer fence attaches to either side of plane with brass thumbscrews; set screw adjusts fence square to sole; 2" tall face for planing edges perfectly square and can be used to shoot angles less than 90° by attaching wooden guide to inside face of fence. Weighs /2 lb. Bevel-up Jointer Planes Sole length: 22 Cutter width: /4 Because of my affection for the bevel-up jack plane, youd think Id have the same enthusiasm for the bevel-up jointer. Not so much. The bevel-up jointer plane is easier to use than its bevel-down cousin. And it is less expensive. But it also has a lower center of gravity, and I think thats why Im not as fond of it. The high center of gravity of the bevel-down jointer plane makes it easier for me to sense when the tool is tipping to the left or right. In other words, I can feel plumb better with a bevel-down jointer plane. The bevel-up jointer. The bevel-up blade configuration results in a plane that is versatile and straightforward to use. The 12° bed angle, coupled with the 25° blade bevel, creates an effective cutting angle of 37°. Simply increasing the blade bevel results in higher cutting angles for improved performance in more difficult-grained woods. Includes a lapped 3/16" (") thick blade, 2 1/4" wide, in your choice of A2, O1 or PM-V11 tool steel. For working difficult grain, lapped 38° and 50° blades and a toothed A2 blade are available. The Veritas low-angle jointer fence (available separately) enables. I Jointer Plane Bevel Up Or Down On thought, "Come on! Bottom Line. Some people really like the four-finger grip, and I believe them and think that bevel-up planes are ideal for this sort of hand preference. Thanks for your dedication. Other Differences. Wilbur Pan October 23, at PM. Well, I had the pleasure of attending two joniter on plane craft by Graham and the one thing I came away with on the second seminar was:.

Difference 2: Grip. One subtle difference is that the bevel-up planes encourage a four-finger grip, while the Bailey-style planes encourage a three-finger grip. Some people really like the four-finger grip, and I believe them and think that bevel-up planes are ideal for this sort of hand preference.

I like the three-finger grip and use it on my drills, saws and planes. I think having the index finger extended is a cue to your brain and helps guide your work straighter.

You can use a three-finger grip with bevel-up planes I do but it feels weird having your finger suspended above the tool in space with nothing to support it. Difference 3: Chipbreakers.

I say this all the time: I really dislike chipbreakers, cap irons or whatever you want to call them. I think they are the No. Chipbreakers are found on all Bailey-style planes, and this is one of their major demerits.

The bevel-up planes have no chipbreaker. And I marvel every time at how easy they are to set up and maintain because of that missing chunk of steel frustration. Difference 4: Throat Adjustment.

If you want to adjust the throat on your Bailey-style plane, settle in. Even the best Bailey planes with a Bed Rock mechanism require some fussing and back and forth to get a tight throat opening. Older Bailey planes require you to disassemble the frog. In contrast, the throat on a bevel-up plane is a cakewalk to adjust. You loosen a knob and slide a shoe plate as close or as far away from the cutting edge as you like.

Nothing could be simpler or more intuitive. This is another big advantage for bevel-up planes if you make any throat adjustments in your work , and many people with just a plane or two do this.

Other Differences. The bevel-up planes have more of their mass low on the tool. The Bailey-style planes can be a bit top-heavy. The funny thing is, I like top-heavy. I believe it. I chalk this up to what you are used to. I have become more comfortable with the balance of the bevel-up planes over the years, but I still favor the top-heavy feel of the Bailey. Also, the bevel-up configuration allows you to change the angle of attack of your tool by honing a different angle on your cutting edge.

With the bevel-down planes, this is harder to control and involves back bevels or shims or other work-arounds. Well, I had the pleasure of attending two classes on plane craft by Graham and the one thing I came away with on the second seminar was:. I thought, "Come on! Not possible! No way! He said the secret which is really no secret, only a lesson that needs passing on to those of us learning on our own , is to:.
