After this calibration, all cuts will be accurate at any miter angle. For non-detent angles you align the pointer to a corresponding mark on the scale. On the Miter SE shown you do this in two locations.
A threaded pin on the Woodhaven miter gauges ensures spot-on angles. To set other angles, you align the fence face with markings on an etched scale, shown below ; we found them equally accurate.
Six of the eight tested miter gauges and all but one sled come with a fence that not only secures and orients the workpiece, but also helps make repeated cuts of identical length when using an adjustable stop. All the miter-gauge fences have accurate scales, but we found it easiest to set the length stops on the Kreg and JDS Accu-Miter The Incra Miter is the only sled with a fence scale; with the others you must measure from the blade. We like having the ability to extend the fence and stop to more than 30" for cutting long project parts, such as table legs.
The breakaway tab on the Kreg fence flip-stop, when removed, lets you use the stop accurately with an attached auxiliary face. To set your miter gauge this way, you align the primary angle pointer on the miter gauge with the nearest whole number you want but not dropped into a detent. Then you rotate the head slightly until the needed vernier mark lines up with the nearest whole-angle mark on the main scale. For example, in the photo below , this gauge is set to cut a miter at And the cutting awards go to And it does this without being cumbersome.
But you could also get both sleds and make all your angled cuts as well as panel cuts, and never need a miter gauge. The 18"-long fence telescopes out for crosscuts up to 34" long, and the stop works on the extension as well as the main fence.
The flip-stop has two independent, adjustable steps for cutting two different lengths in the same setup. A chart on the head provides quick reference to set angles for projects with 4, 5, 6, 8, 9, 10, 12, 15, 18, and 20 sides.
The fence and stop extend for up to a 51"-long crosscut, and the microadjuster was easy to use. The replaceable L-shaped zero-clearance block attaches to T-track on the back of the fence to prevent workpiece tear-out. It uses the same fence stop as the Miter HD, but its 27"-long fence extends to a test-topping 52".
Fence adjustments require the included hex wrench as on the Miter HD. Its overall length and weight make it more cumbersome to use than other models with fences. A swing-out length stop at the end of the fence gives you repeatable accuracy up to 47". The miter bar fits easily with top-side adjusters. The Miter is the most-feature rich miter gauge on the planet with the single exception of the Miter SE.
It delivers perfect, repeatable accuracy. The Miter blends the incremental angle control features of the Miter SE with a very special 3-panel Sled for the ultimate miter cutting workstation for the table saw.
Miter Express offers any miter gauge owner the safest and most accurate cross-cutting and mitering platform available. All Rights Reserved. There are currently no reviews for this product. Be the first to review this product. Looking for parts? Let us know what you need in the form, or give us a call at Company Name.
Model Year Part Number. What is the Elite Advantage? Price Matching The best prices on the web. Customer Service Our customers matter. Knowledgeable Staff In our business, information is king.
